KARL SUSS MJB-3 Mask Aligner

Screen Shot 2016-08-20 at 10.39.05 AM.png
Screen Shot 2016-08-20 at 5.45.59 PM.png
Screen Shot 2016-08-20 at 5.46.18 PM.png
Screen Shot 2016-08-20 at 5.46.44 PM.png
Screen Shot 2016-08-20 at 5.48.12 PM.png
Screen Shot 2016-08-20 at 10.39.05 AM.png
Screen Shot 2016-08-20 at 5.45.59 PM.png
Screen Shot 2016-08-20 at 5.46.18 PM.png
Screen Shot 2016-08-20 at 5.46.44 PM.png
Screen Shot 2016-08-20 at 5.48.12 PM.png

KARL SUSS MJB-3 Mask Aligner

29,500.00

KARL SUSS MJB-3 Mask Aligner



Condition: Used



The Karl Suss MJB 3 Mask Aligner is designed for high resolution photolithography in a laboratory, development or pilot production environment. The MJB 3 offers unsurpassed flexibility in the handling of irregular shaped substrates and pieces of differing thickness, as well as standard size wafers up to 3" in diameter.

Microscope:    M400 Normalfield with revolving objective turret and trinocular microscope head

Microscope Objectives:    Leitz NPL 5X, 10X, and 20X objectives

Microscope Oculars:    10X eyepieces

Lamphouse:    350W lamphouse

Lamp:    350W High Pressure Mercury (Hg) lamp is currently installed

Exposure Optics:    UV400

Optical Sensor:    CH1: 365nm, CH2: 405nm

Timer:    Digital

CIC Power Supply:    CIC 1000 constant intensity controller

NOTE:    THIS MJB 3 CAN ALSO BE ORDERED FOR THE FOLLOWING CONFIGURATIONS:
DUV APPLICATIONS (254nm) IR ALIGNMENT.  PLEASE CONTACT US FOR DETAILS AND PRICING

Tooling:    Includes one (1) set of standard mask holder and matching wafer alignment chuck to customer''s desired wafer size

Vib/Iso Table:    Sold separately; subject to availability at time of order

Selling "as is, where is." We do not have the ability to test all equipment. This system was de-installed in working, operational condition.


PRICES MAY VARY DUE TO AVAILABILITY / CUSTOMER REQUIREMENTS.

PLEASE CALL OR EMAIL FOR FORMAL QUOTATION.

Add To Cart

The Karl Suss MJB 3 Mask Aligner is designed for high resolution photolithography in a laboratory, development or pilot production environment. The MJB 3 offers unsurpassed flexibility in the handling of irregular shaped substrates and pieces of differing thickness, as well as standard size wafers up to 3" in diameter.

Microscope:    M400 Normalfield with revolving objective turret and trinocular microscope head

Microscope Objectives:    Leitz NPL 5X, 10X, and 20X objectives

Microscope Oculars:    10X eyepieces

Lamphouse:    350W lamphouse

Lamp:    350W High Pressure Mercury (Hg) lamp is currently installed

Exposure Optics:    UV400

Optical Sensor:    CH1: 365nm, CH2: 405nm

Timer:    Digital

CIC Power Supply:    CIC 1000 constant intensity controller

NOTE:    THIS MJB 3 CAN ALSO BE ORDERED FOR THE FOLLOWING CONFIGURATIONS:
DUV APPLICATIONS (254nm) IR ALIGNMENT.  PLEASE CONTACT US FOR DETAILS AND PRICING

Tooling:    Includes one (1) set of standard mask holder and matching wafer alignment chuck to customer''s desired wafer size

Vib/Iso Table:    Sold separately; subject to availability at time of order




PRICES MAY VARY DUE TO AVAILABILITY / CUSTOMER REQUIREMENTS.

PLEASE CALL OR EMAIL FOR FORMAL QUOTATION.
